Motor Brand - Bafang
Motor Type - Rear Hub-Drive
Motor Nominal Output - 750 Watts
Motor Peak Output - 1000 Watts
Battery Brand - Samsung Cells
Battery Voltage - 48V
Battery Ah - 20Ah
Battery Wh - 960Wh
Battery Chemistry - Li-NMC
Battery Charge Time (from empty) - 10 Hours
Minimum Range - 35 Miles (56 Kilometers)
Maximum Range - 65 Miles (105 Kilometers)
Display Type - Magnum Branded VeloFox, 8 x 7 cm. Display Screen, Backlit Monochrome LCD
Display Readouts - Battery Level, Assist Level, Current Speed, Power Output, Trip Distance, Odometer, Range, Trip Time
Drive Mode - Torque Sensor Pedal Assist, Twist Throttle, Walk Mode
Lights - Front light controlled from the display. Rear light brake activated. Front Light: 40 lux, Rear Light: 20 lux (Rear light not included)
MECHANICAL DETAILS
Frame material - Aluminum Alloy
Frame size - 19” (48 cm)
Fork Details - XCM34-Boost
Gearing details - A11-X 11-Speed
Shifter Details - A11-X 11-Speed
Crank - Aluminum Alloy, 42T, 170mm
Pedals - Wellgo
Stem - Magnum 60mm
Brakes - Logan Hydraulic Disc Brakes
Grips - Black
Saddle - Selle Royal Essenza+
Tire Brand - CST Patrol 27.5 x 2.8
Wheel size - 27.5”
Fenders - Front and Rear Included
Chain - KMC 11-Speed
MEASUREMENTS
Seat Tube - 19” (48 cm)
Reach - 14.5” (37 cm)
Stand Over Height - 31” (78.5 cm)
Virtual Top Tube Length - 23.25” (59 cm)
Min Saddle Height - 22” (56 cm)
Max Saddle Height - 31” (78.5 cm)
Width - 28.75” (73 cm)
Wheelbase - 45.75” (116 cm)
Length - 74” (188 cm)
Total Weight - 66 lbs. (30 kg)
Battery Weight - 9 lbs. (4 kg)
Recommended Minimum Rider Height - 5’6”
WHAT'S INCLUDED
Kickstand - Center-Mounted Single Side Kickstand
Bell - N/A
Charger - 48 V / 2 A
Front Rack - Optional Front Rack (Not Included)
Rear Rack - Optional (not included)
Fenders - Front and Rear Included
Accessory Mounts - Top Tube Mounts, Head Tube Mounts, Rear Rack Mounts
